Transverse Strength Attachment VTS

Transverse Strength Attachment VTS


  • 1.1 General information

    Transverse Strength Attachment is suitable to connect to Universal strength machine model VUD/VUN (Digital/Hydraulic). It can measure the strength of an AFS 1”X1” or Metric 7/8”X7/8” cross-section area transverse specimen.

  • 1.2 General Usage

    Keep the specimen in between two point support & single point support, start the test cycle & get the transverse strength reading on base equipment.

  • 1.3 Product Data

    Product Name:

    Transverse Strength Attachment

    Product Code:


    Order Reference Code:


    Electrical Supply Required:

    Required for base equipment

    Electrical Plug:

    Not Applicable

    Typical Maximum Current:

    Not Applicable

    Compressed air Supply:

    Not Required


    Not Applicable


    200x50x90mm (WXBXH)

    Packing Dimensions:

    230x230x130mm (WXBXH) Typical

    Net Weight:

    Approximately 0.5 kg

    Gross Weight:

    Approximately 1 kg


    Factory Default

    Measuring Range:

    500 Kg/cm2 (Model VUN)

    600 Kg/cm2  (Model VUD)

    Traceable to:

    Manufacturers Standards

    Least Count:

    10 Kg/cm2 (Model VUN)

    1 Kg/cm2  (Model VUD)

    Specimen Requirements:

    Transverse type

    Operating Temperature:

    0-50 degree Celsius

    Testing Standards:

    BIS: Standard

    AFS: Optional

    Calibration Frequency:

    15500 nos. of Testing Cycles or Once in Year

  • 2.1 Scope of supply

    • Transverse Strength Attachment.(Pair of specimen support)
    • Instruction manual.
  • 3.1 Recommended pre-requisite equipment

    Universal Strength Machine Digital VUD  or

    Universal Strength Machine VUN

    Specimen preparation equipment’s to make a standard AFS or Metric specimen

  • 4.1 Recommended Calibration kits


  • 4.2 Recommended attachments


  • 4.3 Alternative equipment


  • 5.1 Consumables
